Shandong Better Environmental Protection Technology Co.,ltd relying on years of development, it clearly understands the needs of users and the pain points of the industry, and relying on strong technical capabilities to develop high-quality Manufacturer of sand/active carbon filter for sanitary/municipal/domestic/rain sewage treatment that can meet the needs of users and solve the pain points of the industry. Water Treatment Machinery has won high attention and praise from the industry and market. Shandong Better Environmental Protection Technology Co.,ltd has successfully expanded its business in market in the past few years and it is very possible for the company to have a better development in the future.
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company | Place of Origin: | Shandong, China |
| Brand Name: | BETTER | Warranty: | 1 Year |
| After-sales Service Provided: | Video technical support, Field installation, commissioning and training, Field maintenance and repair service, Free spare parts, Online support | Working Temp.: | 5-50℃ |
| Working Pressure: | 4.5 kgf/cm2 | Application: | Wastewater Treatment |
| Capacity: | 0.125M3~1000M3 | Material: | Carbon Steel/stainless steel |
| Product name: | sand/active carbon mechanical filter equipment | Certification: | ISO9001 |
| Type: | Pure Water Treatment System | Function: | Filtering Suspended Matter |
Water after being treated by this machine can meet the requirement of drinking water standard with turbidity less than 5mg/l. Filtering layer in pressure filter helps cleanse water by removing suspended particles, coagulum, sand, iron, Mn. and colloidal particles that is difficult to be eliminated by ways of precipitation. Suspended particles and solids in industrial waste water can also be well removed.
There are two ways for water inlet:
Single-layer filter is suitable for water with turbidity over 100mg/l, raw water that hasn’t been coagulation-precipitated (reduce filter speed or circulating period for water with higher turbidity), add coagulant before water flows into this filter; Multi-layer filter is suitable for precipitated water with turbidity between 15-20mg/l.
Filtering media are quartz filter, active carbon filter and fiber ball filter etc.
Technical Parameter
Model | Size(mm) | Working Temp. | Working Pressure | Single Height (m) | Double Height(m) | Water Outlet (m3/h) | Weight in empty (kg) | Weight In operation (kg) | ||
Height | Diameter | Quartz sand
| White coal | |||||||
RBGL-1000 | 2897 | 1020 |
5-50℃ |
4.5 kgf/cm2 | 1.2 | 0.7 | 0.5 | 7.85 | 880 | 2638 |
RBGL-1500 | 3469 | 1516 | 1.2 | 0.7 | 0.5 | 17.7 | 1506 | 5400 | ||
RGBL-2000 | 3610 | 2016 | 1.2 | 0.7 | 0.5 | 31.4 | 2455 | 9450 | ||
RGBL-2400 | 4020 | 2420 | 1.2 | 0.7 | 0.5 | 45.2 | 4179 | 1420 | ||
RGBL-2500 | 4020 | 2524 | 1.2 | 0.7 | 0.5 | 49.1 | 4679 | 1579 | ||
RGBL-3000 | 4480 | 3020 | 1.2 | 0.7 | 0.5 | 71 | 6355 | 2300 | ||
RGBL-3200 | 4645 | 3224 | 1.2 | 0.7 | 0.5 | 81 | 7200 | 2500 | ||
