BETTER - Paper Mill Wastewater Plant Treatment Dissolved Air Flotation Daf for Pulp Flat flow type DAF

Paper Mill Wastewater Plant Treatment Dissolved Air Flotation Daf for Pulp is a good example to showcase our research and development capability. If you are interested in our products, welcome to contact us, we are very happy to serve you!
SEND INQUIRY NOW
Processing Capacity:
99%
shipping:
Support Sea freight · Land freight
Customization:
Customized logo (Min. Order: 1 Sets) , Customized packaging (Min. Order: 1 Sets) , Graphic customization (Min. Order: 1 Sets)
SEND INQUIRY NOW
  • Products Details

Everyone needs Paper Mill Wastewater Plant Treatment Dissolved Air Flotation Daf for Pulp, and we can offer you the best quality product of the world. Having carried out multiple tests, our technical staff has proved the use of technology ensures Paper Mill Wastewater Plant Treatment Dissolved Air Flotation Daf for Pulp performance can be fully played out.Customers engaged in the field(s) of Waste Treatment Machinery speak highly of our product. Shandong Better Environmental Protection Technology Co.,ltd have realized the importance of technology. In recent years, we have been investing heavily in technology improvement and upgrades and the research and development of new products. In this way, we can occupy a more competitive position in the industry.

Condition:NewApplicable Industries:slaughter house, textile mill, paper mill, machinery factory, Industrial
Showroom Location:Egypt, Canada, Turkey, United KingdomPlace of Origin:Shandong, China
Brand Name:BetterModel Number:YW
Type:Refuse CollectorWarranty:1 Year
Production Capacity:750-3000L/HMachinery Test Report:Provided
Video outgoing-inspection:ProvidedMarketing Type:New Product 2022
Warranty of core components:1 YearCore Components:Motor, Pump
Weight (KG):4500 kgColor:Silver Grey/Blue/Green/etc
Material:Carbon Steel/SS304/SS316Voltage:220V/380V
Chemicals:PAC+PAMCertificates:ISO9001;BV;National patent
Operation:Automatic RunningAfter Warranty Service:Video technical support
After-sales Service Provided1:Field installation, commissioning and trainingAfter-sales Service Provided2::Field maintenance and repair service

PRODUCT DESCRIPTION
YW series Dissolved Air Flotation is mainly for solid-liquid or liquid-liquid separation. Large sum of micro bubbles produced by dissolving and releasing system adhere to solid or liquid particles with same density as waste water to make the whole float to the surface thus achieve the aim of solid-liquid or liquid-liquid separation.
Technical Parameter
DAF can be divided 5/10/20/30/40/50/60/80/100/150/200/250/300 m3/h by capacity, also can be customized by clients' requirements.
Model
Capacity
(m³/h)
Dissolved Gas water
(m³/h)
Main dynamo power
(KW)
Foam scraper power
(KW)
Air compressor power
(KW)
Dissolved air tank size
(mm)
Overall dimension
(mm)

YW-5
4-5
1.5-2
3
0.55
1.5
φ400×1000
3300×1800×2000
YW-10
8-10
2-3
4
0.55
1.5
φ500×1512
4000×2100×2200
YW-20
15-20
5-7
7.5
0.55
1.5
φ500×1512
4600×2400×2200
YW-30
20-30
6-10
7.5
0.55
1.5
φ500×1512
5200×2600×2400
YW-40
30-40
8-13
7.5
0.75
2.2
φ600×1880
6000×2600×2400
YW-50
40-50
15-20
7.5
0.75
2.2
φ600×1880
7000×2600×2400
YW-60
50-60
18-27
11
0.75
2.2
φ600×1880
7600×2800×2400
YW-70
60-70
22-30
11
0.75
2.2
φ650×2034
8400×2800×2400
YW-80
70-80
24-32
11
0.75
3
φ650×2034
9200×2800×2400
YW-105
90-105
30-35
15
1.5
3
φ700×1980
10000×2800×2600
YW-150
125-150
60-80
22
1.1
4
φ700×1980
13500×2800×2600
YW-200
175-200
80-100
30
1.1
5.5
φ800×2100
15800×2800×2600
YW-250
225-250
100-120
37
1.1
5.5
φ800×2400
15200×3400×2600
YW-300
280-300
120-180
37
1.1
5.5
φ1000×2900
19200×3400×2800
APPLICATION

1.Separation of oily(including emulsified) wastewater from petroleum, chemical and mechanical processes.
2.Recovery of sewage organic matter.(such as recovery of pulp fibers and fillers from paper mill wastewater).
3.Treatment of wastewater with high chroma and low dissolved oxygen.Such as textile printing and dyeing wastewater treatment .
4.Treatment of oxide-rich wastewater containing algae.
5.Treatment of low temperature and low turbidity sewage.
6.Replace secondary sedimentation tank, suitable for the situation that is easy to produce sludge swelling;It is suitable for the concentration of residual activated sludge and convenient for the treatment of filter press.
OUR SERVICE
Product Performance:

1.The DAF machine relies on a large number of micro-bubbles to remove the flocculation of the adhesion reaction,so the flocculation requirements are not high ,which can reduce the flocculation time and save the flocculation agent.

2.High yield per unit area,small pool capacity and floor area,saving land and cost.

3.Convenient sludge discharge ,low water consumption;low moisture content of sludge.

4.Shallow tank body depth ,simple tank structure .The machine can be opened and stopped at any time according to the situation and the actual needs , without affecting the water quality ,easy operation and maintenance.
RECOMMEND PRODUCT
PACKAGING AND TRANSPORTATION
FAQ
Q: How to buy your Dissolved Air Flotation?
A: You can provide us the wastewater composition and discharge standards (connect us for more details). we will recommand you the suitable model equipment.

Q: How to pay?
A: TT and L/C are acceptable and TT will be more appreciated. 30% deposit before producing, 70% balance before loading by TT.

Q: What is the delivery time?
A: It depends on order quantities. Generally speaking, the delivery time will be within 3 to 4 weeks.

Q: How to install after the equipments arriving destination?
A: We will provide detailed illustrations to you. And we will send a technician to guide for installation and debugging. After debugging equipment, he will teach your workers how to use it and how to maintain it.
