With years of development, BETTER occupies an important position in the Water Treatment Machinery industry now. We are always in strict accordance with the international quality standards and quality management system, totally ensuring the product quality. Water Treatment Machinery has passed a series of international quality assurance system and product safety certification . With years of familiarity and expertise in this work area, Shandong Better Environmental Protection Technology Co.,ltd has evolved as an affluent manufacturer and supplier in the market, and there is a great possibility that the company will have a better development in the future.

Condition:NewApplicable Industries:Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
Showroom Location:NoneVideo outgoing-inspection:Provided
Machinery Test Report:ProvidedMarketing Type:New Product 2020
Warranty of core components:1 YearCore Components:Pressure vessel, Pump, Engine, Motor, PLC
Place of Origin:Shandong, ChinaBrand Name:BETTER
Weight:2000 kgSize:540*200*220cm
Power:2kwWarranty:1 Year
Productivity:2000L/HourWeight (KG):1200 kg
Material:Q235 carbon steelcapacity:10-50 M3/d
Color:Customized ColorCertification:ISO9001
Type:AutomaticAfter Warranty Service:Video technical support, Online support, Spare parts, Field maintenance and repair service
Local Service Location:NoneAfter-sales Service Provided:Video technical support, Field installation, commissioning and training, Field maintenance and repair service, Free spare parts, Online support

Product Description
MBBR: A small solution with big results

In a crowded marketplace, moving bed biofilm reactor(MBBR) systems stand out for their practicality, usability and cost
effectiveness. In this article, we detail why the small footprint wastewater treatment solution is so effective for existing
facilities, as well as new sites.
The compact MBBR is a very good solution where the following conditions are :
1. Lack of space to build a conventional wastewater treatment plant.
2. Need for the excellent quality of wastewater, including for its.
3. Agility and speed when staring it up(plug&play)

Watch this picture and you can see different chambers which are the 4 steps of this compact MBR process.
Step 1. Equalization tank
Step 2.Anoxical tank to remove nitrate.
Step3. Aerobic tank with the Aeration system
Step4. Membranes and clear water at the final part.
At the core of the MBBR system is its biofilm carrier elements. biofilm carriers are made from polyethylene and are designed to provide a large protected surface for the bacteria culture that facilitates the removal of biochemical oxygen demand(BOD), ammonia and nitrogen. To achieve this, the carrier elements, which have a density sightly below that of water,are kept suspended in the water by air from the diffuses in the aerobic reactors and by means of a mixer in the
anoxic reactors. Thanks to this approach , MBBR system can perform effectively across a spectrum of applications, including use as a sole bio treatment, a pre-treatment and post treatment.
New case stories report substantial energy and emissions savings!
Don’t miss the the latest news in sewage treatment. In the site of sewage treatment, our company and customers show how upgrades to their water control systems led to a more sustainable production.
please watch this video:
Our team was able to help, designing both MBBR plants in an extremely compact manner. To
this end , the first MBBR plant was able to treat 500 m3 wastewater in a footprint of just 70 m2, similarly,the second 100 tons per day of feeding to the fish with a total hydraulic capacity of 5 m3 every hour despite a footprint less than 20 m2.
The user feel uneasy specifying water treatment systems that they feel unfamiliar with.
Fortunately , MBBR system are inherently easy to operate. From our experience, on-site staff learn how to use the system quickly. However, we are also guidance should an issue occur.
Similarly, when compared to alternative approaches,MBBR represents a cost-effective solution , The technology is quick and easy to install, offering plug and play function, which reduces on-site construction time.
Furthermore , through their life cycle, MBBR systems require minimal maintenance, we've been involved with the technology almost 15 years ago. Over the years, we’ve supplied the solution to more 900 projects.
Through this experience, we’ve been able to grow what’s possible with the system and customise the solution to meet specific site goals, we are also able to provide all these advantages in a standard prefabricated packages.
As such, the reliable and robust MBBR solution is now accessible to all.
Model
0.5
1
3
5
10
20
50
Capacity(t/h)
0.5
1
3
5
10
20
50
Air blower(kw)
0.75
0.75
1.1
1.2
4.4
4.4*2
11.5
Pump(kw)
1.1
1.1
1.1
1.5
1.5
2.2
2.2
Water inlet
BOD 150-600 mg/L
Water outlet
BOD 20-40 mg/L
Floor space(m2)
4.5
6.5
12
15
35
51
76
Packing & Delivery
Company Profile
Shandong Better Environmental Protection Technology Co., Ltd. is a high-tech enterprise which was established through the introduction of US technology and specialized in technical research and development, production, design and construction. The company is located in Shandong Zhucheng, facing the coastal city Qingdao on the east and emerging port Rizhao port on the south, which has a superior location, convenient traffic and well equipped foundation. The company covers an area of 33000 m2, with a registered capital of 23 million yuan and the fixed asset 50 million yuan. At present, there are 185 employees in the company, among the existing staff, there are 76 professional personnel with college degree above or intermediate title above. Over the past few years, the company has been a member of Chinese Environmental Protection Industry, and usually cooperate with Tsinghua University Environment Institute and other renowned domestic professional institutes with a strong ability of non-standard design, manufacture and service. Moreover, the establishment of "Weifang Water Treatment Research Center" gives more strength to the company's technical research and development. With the qualification of environmental protection engineering design and equipment production, the company is able to provide the customers with technical advice, process design, area layout, equipment installation and debugging service, etc.
FAQ
1. who are we?
We are based in Shandong, China, start from 2009,sell to Domestic Market(00.00%),Southeast Asia(00.00%),South America(00.00%),Africa(00.00%),Mid East(00.00%),Eastern Asia(00.00%),Central America(00.00%),Southern Europe(00.00%),South Asia(00.00%). There are total about 101-200 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Sewage Treatment Equipment,Waste Incinerator

4. why should you buy from us not from other suppliers?
We have the strong ability of environmental protection equipment manufacture and design.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES;
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,French
If you have suggestions on wastewater treatment ,we should pick up, drop a comment below.
To receive the design of our engineers directly in your inbox, please call me feel free.
